Clausing Surface Grinder

Description

Clausing Surface Grinder Model: CSG-2A618 Purchased: 2011 MFG #: E1TAJ0208 Basic specs: Core Capacity • Table size: 6" × 18" • Max grinding length: ~18.9" • Max grinding width: ~7" • Max height (table → spindle center): ~18" Travels • Longitudinal travel: o Hydraulic: ~18.9" o Manual: ~20" • Cross travel: o Auto: ~7" o Manual: ~7.7" • Vertical feed: o Handwheel graduation: 0.0001" (very fine control) Spindle / Wheel • Spindle speed: ~3450 RPM • Spindle motor: 2HP unconfirmed • Wheel size (typical): o Diameter: 7"–8" o Width: 1/2"–3/4" o Bore: 1.25" Table & Feed System • Longitudinal movement: Hydraulic • Crossfeed: Motorized (servo/ballscrew) • Vertical: Manual • Table speed: ~196–984 in/min (≈16–82 ft/min) • Auto crossfeed increment: o ~0.0004" to 0.004" per pass (depending on setup) Construction / Mechanical Design • Heavy cast iron base with ribbing (good vibration damping) • Turcite-B coated ways (lower friction, longer wear life) • Precision cartridge spindle: o Angular contact + roller bearing setup • Automatic lubrication system (standard) Physical Specs • Weight: ~1,800 lbs • Footprint: ~71" × 45" × 65" • Power: 480 volt, 3 phase, 4 wire, 15 amp fused, hardwired.
