2008 John Deere 710J Backhoe Tractor

Description

Click Here to View All Active Sierra Auction Listings – Featuring High-End Luxury & Sports Cars, Government-Seized Assets, Donated Vehicles, And Government Fleet Units Including Work Trucks, Tractors, Fire Apparatus, Buses and More! Seller Type Municipal/Government Fleet Hours 4,344 Title Brand No Title - Bill of Sale Title Status No Title Drive Status Starts/Runs **As-Is/Where-Is: No Guarantee On Roadworthiness Or Drive Status** Engine Inline 6-cylinder, 4-cycle, turbocharged Fuel Diesel Transmission Automatic Drive Type RWD Body Type Backhoe Tractor Color Yellow VIN/SERIAL T0710JX168388 Manufacturer's Specifications: General Make: John Deere Construction Model: 710J Year: 2008 (production run 2007–2012) Type: Backhoe Loader Successor to: 710G (2003–2007) Emissions: EPA Tier 3 Engine — John Deere PowerTech 6068T Type: Inline 6-cylinder, 4-cycle, turbocharged diesel Displacement: 8.1L (499 cu in) Horsepower (gross): 127 HP (95 kW) @ 2,200 RPM Horsepower (net): 126 HP (94 kW) Torque: 420 lb-ft (570 Nm) @ 1,400 RPM Torque Rise: 37% Fuel System: Direct injection, Stanadyne fuel pump Combustion: Turbocharged, air-to-air aftercooling Governor: Electronic Electrical System: 12V Battery: 925 CCA Engine Oil Capacity (with filter): 20 qt (19 L) Coolant Capacity: 28.5 qt (27 L) Fuel Tank: 72 gal (272 L) Transmission Type: PowerShift — 5 forward / 3 reverse Autoshift: Standard (automatically shifts based on engine RPM and ground speed) Manual Override: Yes — sealed switch module (SSM) control Torque Converter: Single-stage Max Forward Speed (5th gear): 24.6 mph (39.6 km/h) Max Reverse Speed (3rd gear): 16.2 mph (26.1 km/h) Transmission Oil Capacity: 16 qt (15 L) Drivetrain & Steering Drive: 4WD (MFWD — Mechanical Front Wheel Drive) Steering: Hydrostatic power Steering Configuration: Front steer Differential Lock: Electric foot-actuated Final Drives: Planetary Service Brakes: Inboard oil-immersed multiple disc (4-wheel) Parking Brake: Spring-applied, hydraulic release Hydraulic System Type: Pressure compensated load sensing (PCLS) Pump: Variable displacement axial piston System Pressure: 3,625 psi (250 bar) Flow Rate: 55 gpm (208 L/min) Hydraulic System Capacity: 42 gal (159 L) Lift Mode: Yes — up to 15% greater craning capacity Precision Mode: Yes — reduces hydraulic flow 55% for accurate detail work Backhoe Specifications — Standard Stick Max Digging Depth: 17 ft 10 in (5,440 mm) Digging Depth (2 ft flat bottom): 17 ft 7 in (5,360 mm) Load Height: 14 ft 3 in (4,340 mm) Reach from Swing Pivot @ Ground: 22 ft 6 in (6,860 mm) Swing Arc: 180 degrees Bucket Rotation: 205 degrees Bucket Digging Force: 17,000 lbs (7,711 kg) Crowd Digging Force: 11,500 lbs (5,216 kg) Stabilizer Spread (operating): 13 ft 1 in (3,990 mm) Stabilizer Spread (transport): 7 ft 11 in (2,410 mm) Backhoe Specifications — Extendable Stick Max Digging Depth: 22 ft 4 in (6,810 mm) Load Height: 17 ft 0 in (5,180 mm) Reach from Swing Pivot @ Ground: 26 ft 10 in (8,190 mm) Swing Arc: 180 degrees Bucket Rotation: 205 degrees Bucket Digging Force: 17,000 lbs (7,711 kg) Loader Specifications Breakout Force: 15,300 lbs (6,940 kg) Lift Capacity (at bucket pin): 7,900 lbs (3,583 kg) Max Bucket Hinge Pin Height: 13 ft 1 in (3,988 mm) Dump Clearance at Full Height: 9 ft 10 in (2,997 mm) Dump Reach at Full Height: 38.0 in (965 mm) Max Operating Height: 17 ft 0 in (5,182 mm) Bucket Width: 96 in (2,438 mm) Bucket Capacity (heaped): 44 **Disclaimer: The manufacturer's specifications provided are for reference only, and we disclaim any liability for inaccuracies or discrepancies. Specifications may vary by model or trim, and stock photos are used for illustrative purposes only and may not accurately represent the actual product. Please refer to the actual product for precise de
