Komatsu FG70-5 15,000 lb Fork Truck

Full Description

1989 Komatsu FG70-5 15,000 lb Fork Truck. S/N: 80002. This fork truck runs and has 2737 hours. It was last driven about late 2025 to its current storage location. Last complete preventative maintenance was performed on 9/16/2025. The technical specifications for the Komatsu FG70-5 (Serial 80002) reflect its role as a heavy-duty, 7-ton capacity industrial forklift. These specs are primarily drawn from the Komatsu Shop Manual SM024. Engine & Performance Engine: Nissan TB42 6-cylinder, 4.2L engine. Power Output: Approximately 88-89 hp (66 kW) at 2,300 RPM. Torque: 203 lb-ft (275 Nm) at 1,900 RPM. Fuel Type: Dual-Fuel (Gas/LPG). Transmission: TORQFLOW powershift transmission. Lifting Capacity & Mast Rated Capacity: 15,432 lbs (7,000 kg) at a 24-inch (600 mm) load center. Lift Speed (Loaded): Roughly 72 ft/min. Tilting Angle: 6 degrees forward / 12 degrees backward. Physical Dimensions & Weight Service Weight: Approximately 19,800 lbs (9,000 kg) to 20,400 lbs depending on equipment. Length (to Fork Face): Approx. 141 inches (11.7 ft). Overall Width: Approx. 77 inches (6.4 ft). Height (Overhead Guard): Approx. 96-99 inches (8 ft). Turning Radius: Approx. 131-132 inches (11 ft). Ground Clearance: Approx. 11 inches. Maintenance Standards Hydraulic Relief Pressure: 17.5 MPa (approx. 2,540 psi). Fuel Tank Capacity: Approx. 37 gallons (140 liters). Tire Type: Pneumatic Internal tag # P923. Condition: Good Dimensions: L12.00 X W7.00 X H8.00 Feet
