SCAG Tiger Cub Zero-Turn Mower

Full Description

SCAG Tiger Cub Zero-Turn Mower — Specification Sheet Manufacturer: SCAG Power Equipment Series: Tiger Cub Model: STC52A-24HN Serial Number: 8750423 Model Year: Approximately 2003 Equipment Type: Commercial zero-turn riding mower Engine Manufacturer: Honda Rated power: 24 HP Fuel type: Unleaded gasoline, minimum 87 octane Configuration: Commercial-duty, four-cycle, twin-cylinder engine Cooling: Air-cooled Starting system: 12-volt electric start Charging system: Engine-driven alternator Cutting System Cutting width: 52 inches Deck type: SCAG Advantage floating commercial deck Deck construction: Heavy-duty fabricated steel Deck skirt: 7-gauge steel Number of blades: Three Cutting-height range: 1 to 5½ inches Height increments: ¼ inch Deck adjustment: Foot-operated from the operator’s position Blade engagement: Electric PTO clutch Discharge: Side discharge with spring-loaded chute Spindles: Heavy-duty cast housings with tapered roller bearings Anti-scalp protection: Deck-mounted anti-scalp wheels Drive System Drive type: Dual hydrostatic Hydraulic pumps: Two Hydro-Gear BDP-10A variable-displacement pumps Wheel motors: Two cast-iron, high-torque hydraulic motors Steering: Dual-lever independent wheel control Forward speed: 0–10 MPH Reverse speed: 0–5 MPH Parking brake: Lever-operated mechanical brake system Capacities and Running Gear Fuel capacity: Two 4½-gallon tanks—approximately 9 gallons total Hydraulic reservoir: Approximately 2½ quarts Front tires: 13 × 5.00-6, four-ply Rear drive tires: 23 × 9.50-12, four-ply Electrical system: 12 volts Safety equipment: Operator-presence seat switch, neutral controls, parking-brake interlock and PTO interlock Hour meter: Factory-equipped Estimated Productivity Rated coverage: Approximately 23 acres per eight-hour workday under favorable conditions Transport speed: Up to 10 MPH Serial number 8750423 falls within SCAG’s documented 8750000–8759999 production range for the STC52A-24HN. The applicable SCAG parts publication is dated November 2002, indicating this is most likely a 2003-model Tiger Cub. RUNNING CONDITION UNKNOWN. Been Sitting up for a year. Needs a battery etc. We will assist in loading.
